Centrifugal Compressor
Centrifugal compressor is a type of dynamic compressor that is used to increase gas pressure by converting its kinetic energy into potential energy.
Contents
From power generation to refrigeration systems, the centrifugal compressor is living a golden age as a piece of equipment. In a context in which achieving the maximum efficiency has become a much sought-after target, the centrifugal compressor has become a key component of many systems. Here’s a look at how it works and its potential advantages.
What is the centrifugal compressor
This compressor is a type of dynamic compressor used to increase the pressure of a gas by converting its kinetic energy into potential energy.
Commonly used in a variety of industrial applications to compress gasses (such as air, natural gas, and refrigerants), its main role is to move gas around. It thus provides compressed air for a wide range of applications, such as pneumatic tools, or manufacturing processes, as well as being key in many high-end refrigeration applications.
It can also be referred to as an impeller compressor, a radial compressor or a turbo compressor, and it is considered as part of the other types of refrigeration compressors.
What are the parts of a centrifugal compressor?
Impeller
the rotating element of the centrifugal compressor, responsible for imparting kinetic energy to the gas and accelerating it outward towards the periphery.
Diffuser
the high-speed gas enters the diffuser after leaving the impeller, so that it converts the high-velocity gas into high-pressure gas by reducing its velocity and increasing its pressure.
Volute or scroll
a curved, stationary casing surrounding the impeller and diffuser, which collects the high-pressure gas from the diffuser and directs it to the compressor outlet.
Inlet Guide Vanes (IGV) or Inlet Diffuser
an optional component, it is in charge of controlling the flow of gas entering the impeller, improving the compressor’s efficiency across different operating conditions.
Bearing and shaft
while the impeller is connected to the compressor’s shaft, it transfers the rotational energy from the driver to the impeller. Bearings support the shaft and allow it to rotate smoothly.
Seals
these are used to prevent gas leakages between the rotating and stationary components.
Cooling and lubrication system
the first is crucial to maintain optimal operating temperatures, while the latter ensures that bearings and other rotating parts are properly lubricated to reduce friction and wear.
Driver
in charge of providing the mechanical power to rotate the impeller, they can be electric motors, steam turbines, gas turbines, internal combustion engines…
Casing
the outermost pressure containing part
Balance drum
its role is to balance the pressure on both discharge and suction sides
Coupling
in charge to transmit power from driver to compressor
How does a centrifugal compressor work?
The centrifugal compressor displays a distinct working process from other types of compressors, such as the screw compressor. In this case, it follows the Bernoulli’s principle, which states that, within the flow of an incompressible fluid (one that has negligible viscosity and follows the laws of fluid dynamics), the total energy of the fluid remains constant along a streamline, being the sum of three components: potential energy, kinetic energy, and pressure energy.
In this compressor, the impeller blades rotate at high speeds, causing the gas to move in a circular path. This motion creates a radial acceleration, accelerating the gas towards the outer periphery of the impeller.
The impeller is in fact the heart of the compressor. This rotating wheel with curved blades is able to draw in the gas from the center and impart kinetic energy to it.
After leaving the impeller, the high-speed gas flows into the diffuser, which then converts the kinetic energy of the gas into pressure energy by slowing it down and increasing its pressure.
Finally, the gas exits the compressor through the discharge nozzle, where it is then ready for further use or processing.
What are the benefits of using a centrifugal compressor?
There are many benefits of using a centrifugal compressor. Some of these benefits include:
- Increased efficiency, lower operating costs, and reduced emissions.
- These compressors are more efficient than other types of compressors. This is because centrifugal compressors use less energy to compress air than other types of compressors. As a result, centrifugal compressors can save you money on your electric bill.
- These compressors also have a lower operating cost than other types of compressors. This is because they require less maintenance and have a longer lifespan. Additionally, centrifugal compressors produce less emissions than other types of compressors. This is because they have a lower carbon footprint.
What are some of the applications of centrifugal compressors?
Centrifugal compressors are used in a variety of industrial and commercial applications. Some of the most common applications include:
- Air conditioning and refrigeration
- Pulp and paper processing
- Petrochemical processing
- Power generation
- Food and beverage processing
- Pharmaceutical production
Get in touch with us to learn more about the use of the centrifugal compressor to boost performance in cooling energy systems.
Frequently Asked Questions
A centrifugal compressor is a type of dynamic compressor used to increase the pressure of a gas by converting its kinetic energy into potential energy.
The centrifugal compressor displays a distinct working process from other types of compressors, such as the screw compressor. In this case, it follows the Bernoulli’s principle, which states that, within the flow of an incompressible fluid (one that has negligible viscosity and follows the laws of fluid dynamics), the total energy of the fluid remains constant along a streamline, being the sum of three components: potential energy, kinetic energy, and pressure energy.
